PG-SS--10 4" All SS gauge

1. For gaseous and liquid aggressive media that are not highly viscous or crystallising, also in aggressive ambiance.
2. Process industry: Chemical/petro-chemical, power stations, mining, on- and offshore, environmental technology, machine building and general plant construction.


Product Features:
  • Nominal Size: 100mm
  • Accuracy: 1.6% or 1.0% F.S
  • Connection Material: SS304 or SS316L
  • Connection thread: 1/2 (BSP, PT, NPT)

Product Detail

Product Tags

Design

EN837-1

Description

Stainless steel pressure gauge

Nominal size in mm

100

Accuracy class

1.6 or 1.0

Scale ranges

0~1000bar (customised range)

Permissible temperature

Ambient: -40~+60℃ without filling; -5~+60℃ with filling
Medium: +200℃ without filling; +100℃ with filling

Process connection

S.S 304 or S.S 316L

Connection thread

1/2 (G PT NPT)

Bourdon tube

S.S 316L

Movement

S.S 304

Case

S.S 304

Bezel

S.S 304 Bayonet

Flange

S.S 304

Window

Laminated safety glass

Dial

Aluminum (customized logo)

Pointer

Aluminum, black

Ingress protection

IP65
